- Fields of application: Pneumatic, oleodynamic and hydraulic circuits;
- Operating pressure: The maximum operating pressure depends on the pipe characteristics. Maximum pressure 16 bar (1;6 MPa);
- Operating temperature: -10°C (263°K) ÷+80°C (353°K);
- Pipes to be connected: RILSAN (PA11/12), POLYURETHANE, POLYETHYLENE, POLYESTER, PTFE, NYLON (PA6): ±0,05 (ø 4÷ø10) - ±0,1 (ø12 ÷ ø 14);
- Materials used: Nickel-plated brass (UNI EN 12164 CW 614N), Nickel-plated ZAMA-15 (UNI EN 1774:99);
- Thread: Gas conical thread with PTFE ISO 7 (BSPT) - DIN 2999 - BS 21; Cylindrical gas thread - ISO 228 (BSPP);
- The products comply with the 2002/95/EG – RoHS directive.
- Ref
- AH032704
- EAN
- 8022219003292
- Brand
- 38
- Thread height
- 11,5 MM
- Diameter
- 12 X 10 MM
- Shackle
- 3/8M
- Weight
- 37,5 G
ANI is known worldwide for the production and sale of accessories for compressed air as well as paint spray guns. ANI is a world leader in the compressed air market where it has been present for 50 years. It has a product range for car body shops, car repair, wood industry, building, tool-making such as lubricators, filters and pressure regulators, among other tools and hardware.
