FIELDS OF APPLICATION: Pneumatic circuits;
OPERATING PRESSURE:
- The maximum operating pressure depends on the pipe characteristics;
- Maximum pressure 16 bar (1.6 MPa);
OPERATING TEMPERATURE: -10°C (263°K) ÷ +80°C (353°K);PIPES TO BE CONNECTED: RILSAN (PA11/12), POLYURETHANE, POLYETHYLENE, POLYESTER, PTFE, NYLON (PA6) ±0,05 (ø 4÷ø10)- ±0,1 (ø12 ÷ ø 14);
MATERIALS USED: Nickel-plated brass (UNI EN 12164 CW 614N), Nickel-plated ZAMAK-15 (UNI EN 1774: 99);
O-RINGS/WASHERS: Oil-resistant, silicone-free NBR washers;
THREAD:
- Gas conical thread with PTFE- ISO 7 (BSPT)- DIN 2999- BS 21;
- Cylindrical gas THREAD: - ISO 228 (BSPP);
The products comply with the 2002/95/EG – RoHS directive.
- Ref
- AH037308
- EAN
- 8022219248952
- Brand
- 38
ANI is known worldwide for the production and sale of accessories for compressed air as well as paint spray guns. ANI is a world leader in the compressed air market where it has been present for 50 years. It has a product range for car body shops, car repair, wood industry, building, tool-making such as lubricators, filters and pressure regulators, among other tools and hardware.
