- Pressure regulator with graduated scale 1-9 bar ÷ 20-130 psi;
- Line tap (mod. 31/S4- AIR 11);
- Piston-type pressure regulation system;
- Regulation knob with locking device and threaded fastening ring in engineering polymer;
- Pressure release valve for overpressure and relieving function supplied as standard.
FIELDS OF APPLICATION: Compressed air;
MATERIALS USED:
- Body: Sandblasted aluminium (GZn Al4 Cu1 UNI EN 1774);
- Knob/Ring/Piston/Valve: Engineering polymer;
- Rod: Brass (CW614N UNI-EN 12164);
- Screw: Steel class 4.8 DIN 7985;
- Springs: Stainless steel (AISI 302 UNI EN 10088-3) Class C steel UNI 3823 W;
- Seal washers: NBR/PTFE rubber;
THREAD: 31/S4- 1/4 F 1/4” BSP- 1/4” BSP; 31/S4- AIR 11 1/4” BSP- bayonet fitting; 31/S6- 1/4 F 1/4” BSP- 1/4” BSP;
OPERATING TEMPERATURE: -25°C (13°F), +50°C (122°F);
OPERATING PRESSURE: 1.5÷9 bar (22 psi÷ 130 psi);
THREAD: 1/4” F BSP Cylindrical gas thread ISO 228 (BSPP).
- Ref
- AH101701
- EAN
- 8022219040914
- Brand
- ANI
ANI is known worldwide for the production and sale of accessories for compressed air as well as paint spray guns. ANI is a world leader in the compressed air market where it has been present for 50 years. It has a product range for car body shops, car repair, wood industry, building, tool-making such as lubricators, filters and pressure regulators, among other tools and hardware.
