- Pressure regulator with round gauge Ø 40 mm, 0-16 bar ÷ 0-230 psi scale. (class 2.5);
- Line tap (mod. 1/A4- AIR 11 ÷ 31/A7- AIR 11);
- Quick coupler 17/AM (mod. 31/A8 ÷ 31/A9);
- Piston-type pressure regulation system;
- Regulation knob with locking device and threaded fastening ring in engineering polymer;
- Pressure release valve for overpressure and relieving function supplied as standard.
FIELDS OF APPLICATION: Compressed air;
MATERIALS USED:
Body: Sandblasted aluminium (GZn Al4 Cu1 UNI EN 1774);
Knob/Ring/Piston/Valve: Engineering polymer;
Stange: Brass (CW614N UNI-EN 12164);
Screw: Steel class 4.8 DIN 7985;
Springs: Stainless steel (AISI 302 UNI EN 10088-3) Class C steel UNI 3823- Steel Acier;
Seal washers: NBR/PTFE rubber;THREAD: 31/S4- AIR 11 1/4” BSP- bayonet fitting; 31/A7- N°2 AIR 11 1/4” BSP- bayonet fitting; 31/A8- 17/AM 1/4” BSP- quick coupler;31/A9- N°2 17/AM 1/4” BSP- quick coupler;
OPERATING TEMPERATURE: -25°C (13°F), +50°C (122°F);
OPERATING PRESSURE: 1.5÷9 bar (22 psi÷ 130 psi);
THR
- Ref
- AH102002
- EAN
- 8022219041324
- Brand
- 38
ANI is known worldwide for the production and sale of accessories for compressed air as well as paint spray guns. ANI is a world leader in the compressed air market where it has been present for 50 years. It has a product range for car body shops, car repair, wood industry, building, tool-making such as lubricators, filters and pressure regulators, among other tools and hardware.
