MEGA Hydraulic Cylinder General Purpose Double-Acting CDRA-23D 23t

Ready to Ship
CDRA-23D
- Working pressure: 700 kg/cm2/10.000 psi;
- Hydraulic return;
- The piston has a nitriding treatment or a hard chromium coating, depending on the model, to avoid corrosion;
- Bronze guide and scraper seal that prevents the entry of dirt.
equalizer Add to Compare
favorite_border Add to Wishlist
Share
Add to cart 40,00 € and shipping is free
- Working pressure: 700 kg/cm2/10.000 psi;
- Hydraulic return;
- The piston has a nitriding treatment or a hard chromium coating, depending on the model, to avoid corrosion;
- Bronze guide and scraper seal that prevents the entry of dirt;
- The hydraulic force being applied in both directions, these cylinders are very solid and used where a precision operation is required to move or position loads accurately on the assembly place;
- Widely demanded in public works and big structure manufacture;
- Fitted with a relief safety valve, ref. A-5538 on the piston retract side, to prevent accidental overpressure.
Ref
CDRA-23D
EAN
5608907520758
Brand
MEGA
Color
GREY
Weight
10,4 KG
Minimum height
310 MM
Oil capacity
E 500 CM³/T 155 CM³
Rated Capacity
23 T
Stroke
150 MM
Effective Area
E 33,18 CM²/T 10,28 CM²

MEGA


MEGA is a Spanish brand with more than 80 years of history, specialized in automotive and industrial equipment. It designs, builds and distributes hydraulic equipment with a tradition of quality, credibility and knowledge. Jacks, presses, cranes and hydraulic tools are some of MEGA's high-quality categories.


See all product of MEGA

  • Security policy

    Safety payments

  • Delivery policy

    Worldwide shipping

  • Return policy

    Returns within 14 days

Description
- Working pressure: 700 kg/cm2/10.000 psi;
- Hydraulic return;
- The piston has a nitriding treatment or a hard chromium coating, depending on the model, to avoid corrosion;
- Bronze guide and scraper seal that prevents the entry of dirt;
- The hydraulic force being applied in both directions, these cylinders are very solid and used where a precision operation is required to move or position loads accurately on the assembly place;
- Widely demanded in public works and big structure manufacture;
- Fitted with a relief safety valve, ref. A-5538 on the piston retract side, to prevent accidental overpressure.

PRODUCTS DATA
Ref
CDRA-23D
EAN
5608907520758
Brand
MEGA
Color
GREY

SPECIFICATIONS
Weight
10,4 KG
Minimum height
310 MM
Oil capacity
E 500 CM³/T 155 CM³
Rated Capacity
23 T
Stroke
150 MM
Effective Area
E 33,18 CM²/T 10,28 CM²
Brand

MEGA


MEGA is a Spanish brand with more than 80 years of history, specialized in automotive and industrial equipment. It designs, builds and distributes hydraulic equipment with a tradition of quality, credibility and knowledge. Jacks, presses, cranes and hydraulic tools are some of MEGA's high-quality categories.


See all product of MEGA
